BVC control G
BrandTech Scientific
BVC control G
SKU: bt-p5211
$3,344.00
BVC control G from BRAND (BrandTech Scientific). powerful and long-lasting chemistry diaphragm pump for universal economical use
The BioChem-VacuuCenter BVC control serves for efficient and convenient aspiration of supernatants. The vacuum level - and thus the suction force - is exactly adjustable by the electronic touch panel and allows a sensitive and reproducible operation. The chemically resistant diaphragm vacuum pump is automatically turned on and off as needed, which reduces the low noise level even further. The BVC control is available in two complete equipment options with different collection flasks. The 2l borosilicate glass bottle with a protective coating has a very high chemical resistance. For larger amounts of liquids the 4l bottle of unbreakable polypropylene (PP) is used. The smooth surfaces allow an easy cleaning of the systems.
Key Features
Specifications
| Weight | 8.1 kg |
| Manufacturer | BRAND (BrandTech Scientific) |
| Items supplied | Fluid aspiration system complete with powerful chemistry diaphragm pump, collection bottle, adjustable suction power control via touch panel, aspiration hand set VHC pro and protection filter, ready for use with manual. |
| Vacuum controller | Touchpanel |
| Protection class IEC 60529 | IP 40 |
| Max. pumping speed 50 Hz | 0.7 m 3 /h (Vacuum pump) |
| Max. pumping speed 60 Hz | 0.5 cfm (Vacuum pump) |
| Ultimate vacuum | 150 mbar / 112 torr |
| Max. back pressure (abs.) | 1.1 bar |
| Inlet connection | Suction controller |
| Outlet connection | Hose nozzle DN 8 mm / silencer |
| Rated motor power | 0.04 kW |
| Rated motor speed at 50/60 Hz | 1500/1800 min -1 |
| Noise (sound pressure level) in dBA at 50 Hz or 1500 rpm/62% (VARIO)/1500 rpm (VARIO-SP)/12500 Upm (VACUU·PURE®) | 49 dBA |
| NRTL certification | No |
| Rated mains voltage range 1 | 230 V |
| Mains frequency 1 | 50-60 Hz |
| Control range | 150 - 850 mbar (adjustable) |
| Collection bottle | 2l Glass |
